ProSource Handleset, 3 Grade, Keyed Key, Zinc, Aged Bronze, 2-3/8 x 2-3/4 in Backset, KW1 Keyway, Residential

ProSource

ProSource Handleset, 3 Grade, Keyed Key, Zinc, Aged Bronze, 2-3/8 x 2-3/4 in Backset, KW1 Keyway, Residential

$82.99$82.99
ProSource Handleset, 3 Grade, Keyed Key, Zinc, Aged Bronze, 2-3/8 x 2-3/4 in Backset, KW1 Keyway, Residential
  • Backset Size: 2-3/8 x 2-3/4 in
  • Center to Center: 5-1/2 in
  • Commercial/Residential: Residential
  • Cross Bore Diameter: 2-1/8 in
  • Cylinder Type: 5-Pin
  • Model #: HY7X31-PS
  • UPC #: 045734656673
  • SKU: 7001167

Your shopping list will be used for pickup in-store

Product Details

The keyless handleset has a forged solid brass full handle and interior knob with single cylinder deadbolt. The latch bolt is operated by thumbpiece outside and grip inside and the deadbolt is operated by key outside and turn piece inside.

Key Features

  • Keyway: KW1
  • Keyless
  • Made of brass
  • Door handling is reversible

Item Specifications

Backset Size2-3/8 x 2-3/4 in
Center to Center5-1/2 in
Commercial/ResidentialResidential
Cross Bore Diameter2-1/8 in
Cylinder Type5-Pin
Deadbolt Latch Throw1 in
DesignHandleset
Dimensions423 x 400 x 468 mm
Door Thickness1-3/8 to 1-3/4 in
Edge Bore Diameter1 in
Faceplate Size1 x 2-1/4 in
FinishAged Bronze
Grip Center to Center8-5/8 in
Interior Handle TypeT3
Key TypeKeyed
Keyway TypeKW1
Latch Type6-Way
MaterialZinc
Number of Cylinders1
Plain bolt Latch Throw12.5 mm
Plainbolt Latch Throw12.5 mm
Projection Size1 in Deadlock 1/2 in Plain latch
Security Grade3
Strike Size44.8 x 57 mm Knob 25.4 x 57 mm Deadbolt mm
Strike TypeRadius Corner
Suitable forFor Use on Exterior Doors Where Keyed Entry and Security is Needed
